SUSPENSION MAGNET
Application
Minco Suspension Magnets provide effective protection from unwanted iron in grains, feedstuffs, raw and processed food products and other particulates. They are placed above open conveyors to remove large pieces of tramp metal that represent a hazard to downstream crushers, mills, pulverizes and grinders. Suspended electromagnets also remove sharp metal that can damage or tear expensive conveyor belts, especially at transfer points.
Features
- Low operating cost
- No electrical maintenance on magnet
- No costly shutdowns
- Uninterrupted magnetic protection
- Mounting at any angle
- Powerful magnetic field
- No power required
Product Gallery
Specifications
Type | Belt Width (mm) | Belt Speed (m/s) | Suspended Height (mm) | Absorb Capacity (Kg) | Working Mode | Motor Output (kw) | Weight (kg) |
QJRCY-65 | 650 | < 4.5 | 200 | 0.1-35 | Continuous | 1.5 | 830 |
QJRCY-80 | 800 | < 4.5 | 250 | 0.1-35 | Continuous | 2.2 | 1100 |
QJRCY-100 | 1000 | < 4.5 | 300 | 0.1-35 | Continuous | 3.0 | 1710 |
QJRCY-120 | 1200 | < 4.5 | 350 | 0.1-35 | Continuous | 4.0 | 2292 |
QJRCY-140 | 1400 | < 4.5 | 400 | 0.1-35 | Continuous | 4.0 | 3080 |
QJRCY-160 | 1600 | < 4.5 | 450 | 0.1-35 | Continuous | 5.5 | 4130 |
QJRCY-180 | 1800 | < 4.5 | 500 | 0.1-35 | Continuous | 7.5 | 8100 |
QJRCY-200 | 2000 | < 4.5 | 550 | 0.1-35 | Continuous | 7.5 | 11300 |
